Profi COMPLETE RAVAK PRODUCT INFORMATION 2023 www.ravak.com
RAVAK design 4 Concepts 6 Shower enclosures and doors 16 > Walk-In 24 > Brilliant 38 > SmartLine 50 > Matrix 64 > Chrome 76 > Nexty 102 > Pivot 118 > Blix Slim 134 > Blix 152 > Supernova 184 > Atypical products 212 > Spare parts 216 Seats 222 Shower trays, shower channels and floor drain 230 Bathtubs 270 Bath screens and doors 326 Washbasins 350 Bathroom furniture 408 Toilets and bidets 460 Faucets 472 Shower accessories 562 Bathroom accessories 582 Bathroom chemicals 600 Content
4 Simple, original solutions, clear idea for each concept, utility first. Design RAVAK Kryštof Nosál Czech product designer and author of many RAVAK bathroom products. Proponent of uncomplicated, clean solutions. Recipient of Red Dot, iF Design Award, EDIDA, Good Design and many other awards for his RAVAK products. Achim Storz Austrian product designer, author of RAVAK bathtubs as well as car interiors for brands such as Porsche, BMW, Audi and more. Vrtiška & Žák Founders of Prague studio Vrtiška & Žák, with more than a decade-long tradition. They were brought together by their diligence, passion for overcoming challenges, and ability to see potential where others cannot. Their work covers a range of fields, from designing products to interior design and architecture, from handiwork to industrial-scale production. Creativity and unconventional thinking are the core values of their work.
ravak.com 5 RAVAK design has repeatedly met with success in international competitions.
6 Regardless of whether you prefer bathing or showering, or are looking for toilet equipment, RAVAK concepts have all you need. We offer bathtubs, shower enclosures, shower trays, washbasins, furniture, water faucets, toilets and accessories in matching designs, with a clear, logical vision, which has been developed based on years of professional experience. Their original design will never cease to bring joy and delight into your bathroom. RAVAK concepts are a great fit for bathrooms of all sizes, from the smallest to the largest. Only RAVAK offers the broadest, matching bathroom set on the market – the universal Chrome concept, which includes over 200 items for bathrooms and toilets. RAVAK concepts A perfectly matching whole for any bathroom or toilet 4 2
ravak.com 7 1 3 Toilets and bidets - for perfectly matching your bathroom to the toilet 4 Washbasins and bathroom furniture - countertop- or vanity unit-mounted, made of cast marble or ceramics 3 Shower enclosures and doors - precision manufacturing with the use of the highest quality components 2 Bathtubs and bath screens - suitable for both bathing and showering 1 Faucets and bathroom accessories - made from top-quality materials you can rely on 5 5 Concepts
8 Concept Chrome - the widest concept on the Czech market Faucets and accessories See p. 518 Chrome and Chrome Slim rectangular or corner bathtub See p. 294 Shower trays or shower channels See p. 244 Bathroom accessories See p. 590 Washbasins, double washbasin, hand basin and bathroom furniture See p. 426 Bath screen See p. 332 Matching to the most minute detail. Furnishings for the entire bathroom and toilet. Bathtubs now also available in a version with a rim height of only 18 mm. Shower enclosures in various designs See p. 76 Seats See p. 222 Toilet and bidet See p. 462 Design Kryštof Nosál
ravak.com 9 Meets you halfway - Concept 10° Rotation of individual products by a mere 10° stood at the origin of an exceptional concept for bathrooms, both large and small. ergonomics in harmony with innovative design. Bathroom furniture See p. 442 Faucets See p. 512 Corner bathtub with shelf space or seat, or rectangular bathtub See p. 306 Slightly rotation of washbasins provides more comfortable access See p. 388 Bath screen See p. 344 Bathroom accessories See p. 584 Shower trays or shower channels See p. 244 Design Kryštof Nosál
10 Concept Formy - transformation of shapes in two forms Puristically clean set of bathtub and washbasin with a refreshing element of intentional asymmetry. Bathtubs now also available in a version with a rim height of only 18 mm. Bathtub Formy 01 and Formy 01 Slim See p. 286 Washbasin Formy 01 See p. 363 Formy vanity unit See p. 425 Tall cabinet Formy See p. 423 Design Kryštof Nosál Formy 01
ravak.com 11 Transformation of shapes in two forms - Concept Formy Subtle curving of the longitudinal lines of the washbasin and bathtub gave rise to an original concept. Bathtubs now also available in a version with a rim height of only 18 mm. Bathtub Formy 02 and Formy 02 Slim See p. 288 Washbasin Formy 02 See p. 363 Formy vanity unit See p. 425 Tall cabinet Formy See p. 423 Design Kryštof Nosál Formy 02
12 Concept Rosa II - A spacious shower enclosure and large bathtub in one A concept suitable for bathrooms small and large. Comprehensive and timeless solution refined to the last detail. Washbasin vanity units See p. 450 Surprisingly comfortable bathtubs See p. 310 Washbasins in various sizes See p. 394 Bath screens See p. 346 Tall cabinet with shelves See p. 450 Design Kryštof Nosál
ravak.com 13 Simplicity is beauty - Concept Classic II Washbasins, double washbasin and hand basin in different sizes See p. 386 Bathroom furniture in four décors with high-quality impregnation and fittings See p. 446 Bathtubs with a wide, flat bottom See p. 296 Bath screens and doors See p. 326 Richly furnished concept for the entire bathroom or toilet. Timeless design that never bores. WC Classic See p. 466 Faucets See p. 526 Design Kryštof Nosál
14 Concept Avocado - maximum out of minimum The concept consists of a small yet comfortable bathtub with a practical washbasin. Perfectly suited for even the smallest of bathrooms. The most compact bathtub See p. 316 Washbasins with ample shelf space suitable for mounting above a bathtub See p. 402 Design by Achim Storz
ravak.com 15 Sophisticated economical solution - Concept BeHappy II The most space-saving bathroom solution for comfortable bathing and showering. For a small bathroom with big possibilities. Bath screen that can be tilted flat against the wall See p. 340 Vanity unit for straight washbasin See p. 456 Comfortable bathtub for bathing and showering See p. 318 Design Kryštof Nosál Washbasin designed for placement above a bathtub See p. 398
16 Shower enclosures Why RAVAK? We abide by the fundamental rules of responsible production. We oversee the top quality of our products, use modern technologies, but also rely on the timeproven skills of experienced artisans and invest in our in-house design. RAVAK design Our products are not just designed for looks. RAVAK products emphasise functionality and comfort in the bathroom.
ravak.com 17 lasting customer satisfaction We build on 30 years of experience and constant refining of shower enclosures. Nothing is impossible We have a solution for almost any bathroom. glass protection The glass is protected by RAVAK AntiCalc® surface treatment technology Something for everyone We offer 11 model lines and over 500 types of shower enclosures. A brand you can trust All RAVAK shower enclosures come with an extended warranty. Production process under control We manufacture in Europe in our own facility, so that we can have the material quality and manufacturing quality fully under control. iN-houSe deVeloPMeNT ANd iNNoVATioN BRoAd PoRTFolio PRooF oF QuAliTy MAde iN euRoPe ATyPiCAl SoluTioNS glASS PRoTeCTioN Shower enclosures
18 Frame colour design Parameters for choosing shower enclosures and doors You can find and order our range of glass panels for atypical solutions at https://atypical.ravak.com More about atypical products on p. 212. All glass panes are fitted with a protective layer of RAVAK AntiCalc®. Find more on p. 21. The same colour designs and panes are also available for bath screens. See p. 326. Matrix, Chrome, Nexty, Pivot, Blix and Supernova white Walk-In, SmartLine, Matrix, Chrome, Nexty, Pivot, Blix Slim and Blix bright alu Matrix, Chrome, Nexty, Pivot, Blix and Supernova satin Walk-In, Nexty, Pivot, Blix Slim and Supernova black Standard panels For all lines of shower enclosures For Blix and Supernova lines Supernova - for bathtub screens only Supernova transparent pearl grape rain Safety glass Atypical panelling – on demand strip matelux matrix graphite Safety glass with print or tint Plastic panelling
ravak.com 19 Design Brilliant, Walk-In, SmartLine, Chrome Shape frameless Matrix, Nexty, Pivot, Blix Slim, Blix, Supernova framed Type of the opening system quadrant square rectangle SmartLine, Chrome, Nexty, Pivot, Blix Slim, Blix, Supernova Brilliant, SmartLine, Matrix, Chrome, Nexty, Pivot, Blix Slim, Blix, Supernova Brilliant, SmartLine, Matrix, Chrome, Nexty, Pivot, Blix Slim, Blix, Supernova Walk-In Walk-In doors Brilliant, SmartLine, Matrix, Chrome, Nexty, Pivot, Blix Slim, Blix, Supernova With rotary column – in and out Hinged – out Swinging pivot – out Folding - Sliding Sliding Chrome Brilliant, SmartLine Nexty, Pivot, Supernova Blix, Supernova Matrix, Blix Slim, Blix, Supernova
20 Frame at the bottom of the shower enclosure: Nexty, Pivot, Blix Slim, Blix, Supernova Threshold strip at the bottom of the shower enclosure: Brilliant, SmartLine, Matrix, Chrome Framed shower enclosures provide optimal prevention of water spraying into the bathroom. The taller the bottom, horizontal profile, the better the protection. The shower enclosure or door will thus hold water inside the shower enclosure, even during intense showering. Extension profi les Allows adjusting (expanding) a shower enclosure or door (or bath screen) by exactly 2 cm on each side. Extension profi les are available for the following shower enclosure and door lines: Nexty, Pivot,, Blix and Supernova. Fixing profi les Used for affixing the shower enclosure or door to the wall. included with every product that requires it. Fixing profile extension profile extension profile 20 mm 0 -10 +10 The shower enclosure can be shifted by 10mm in both directions in the fi xing profi le. 20 mm ExTENSION PROFILE Shower enclosure /Graphical example of use with Supernova shower enclosure/ Extended fi xing profi le Fixing profiles Chrome A standard fi xing profi le is included with every Chrome product and allows adjusting (expanding/narrowing) the product by 10 mm. white bright alu satin extended Chrome fixing profile 0 -10 +10 30 mm Standard Chrome fixing profile 10 mm -10 +10 0 if you need to expand the product more than that, it is necessary to buy a new, extended fi xing profi le, which is 20 mm wider and allows extending the product by an extra 20 mm, while retaining the +/- 10 mm adjustability. SeAliNg QuAliTy FiXiNg ANd eXTeNSioN PRoFileS FoR NeXTy, PiVoT, BliX, SuPeRNoVA
ravak.com 21 RAVAK AntiCalc® technology Glass treated with RAVAK AntiCalc® – water is repelled and runs down the glass. Effects of water on glass without the use of RAVAK AntiCalc®. An invisible shield against dirt and deposits on the glass All water except for rainwater and distilled water contains a certain amount of salts. Their deposits, known as scale, can only be removed with great difficulty. They form a chemical bond with the glass and give it an unsightly tint over time. Common chemical cleaning products are entirely ineffective against scale. Only the patented RAVAK AntiCalc® technology can reliably protect glass from these permanent stains. All RAVAK shower enclosures and screen glass panes are treated with RAVAK AntiCalc® during production. The complete assortment of RAVAK detergents can be found on p. 601. /microscopic detail of glass / surface of common glass Surface of glass treated with RAVAK AntiCalc® RAVAK AntiCalc Conditioner It is recommended to renew the water-repellent effects of our technology every 3 months (depending on water hardness) by applying RAVAK AntiCalc Conditioner. The BeST SeRViCe CoMeS diReCTly FRoM The MANuFACTuReR
22 We offer more than 500 types of shower enclosures in eleven model lines. Overview of model lines Brilliant > 38 Walk-In > 24 Chrome > 76 Pivot > 118 Nexty > 102
ravak.com 23 5 5-YEAR WARRANTY ON ALL SHOWER ENCLOSURES AND DOORS Supernova > 184 Blix Slim > 134 SmartLine > 50 Matrix > 64 Blix > 152
24 Walk-In
ravak.com 25 GLASS PROTECTION The glass is protected by RAVAK AntiCalc® surface treatment technology EASY MAINTENANCE No profiles or inaccessible places 5 5-YEAR WARRANTY ON ALL SHOWER ENCLOSURES AND DOORS Walk-In Free > 26 Walk-In Corner > 28 Walk-In Wall > 30 Walk-In Double Wall > 32 Modern solution Reflects the current trend of transparent glass and airy bathrooms Broad range of designs Offers a number of structural designs (Free, Corner, Wall, Double Wall,…) Option to choose from standard or atypical sizes (up to a width of 160cm and height of 250 cm). Option to choose entrance width. Subtle metal fittings Do not intrude visually and safely hold the glass in place Universal struts Can be shortened to the desired length Easy maintenance Thanks to a protective RAVAK AntiCalc® layer, the glass stays clean for longer (no scale sediments) GLASS THICKNESS 8 mm Shower enclosures Walk-In
26 Elegant metal strut that fits the clean look of the enclosure Minimalist chromed rest matches the top strut Walk-In Walk-In Free One fixed wall with entrance from both sides Shower channels 262 è An icon of stylish bathrooms. The use of only a single fixed wall allows entry into the showering area from both sides. Ideal for showering for two. Spacious and airy 5. 8 mm safety glass with patented RAVAK AntiCalc® technology. 4. The W SET contains metal struts, U washers, glass seals and the mounting kit. The glass pane package includes the glass pane and a fixing profile. 3. W SET-Uni Free/Wall has a length of 120 cm. Can be cut to shorten it to any size and create the exact entrance width you need. 2. To complete your shower enclosure, it is necessary to order the Walk-In Free glass pane along with two W SETUni Free/Wall (recommended), or with one W SET-Free of the chosen size. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Seats 222 è Faucets 472 è Accessories 564 è Detergents 601 è
ravak.com 27 BRIGHT ALU TRANSPARENT GRAPHITE BLACK MATELux MATRIx Design Standard panelling Atypical panelling Products are delivered within 14 days as standard. For a complete product, it is necessary to order a Walk-In Free glass pane pack separately and a W SET separately. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks. 5-YEAR WARRANTY 5 GLASS PROTECTION ANTICALC EASY MAINTENANCE GLASS THICKNESS 8 mm Walk-In Free Order No. Type Frame Panelling Product dimensions (mm) „V“ entrance (mm) Size of packaging (cm) Gross weight (kg) GW9FG0C00Z1 Walk-In Free - 120 - transparent 1200 125x8x205 57 GW9FJ0C00Z1 Walk-In Free - 130 - transparent 1300 135x8x205 60.4 GW9FM0C00Z1 Walk-In Free - 140 - transparent 1400 145x8x205 69 GW9FP0C00Z1 Walk-In Free - 150 - transparent 1500 155x8x205 69.8 GW9FS0C00Z1 Walk-In Free - 160 - transparent 1600 165x8x205 77 GWD01000A098 W SET - Uni Free/Wall bright alu - --- max. 1200 6x10x125 1.46 GWD010003023 W SET - Uni Free/Wall black - --- max. 1200 6x10x125 1.45 GWD01000A096 W SET - 90 Free bright alu - --- 900 120x7,4x5 1.72 GWD010003020 W SET - 90 Free black - --- 900 120x7,4x5 1.72 GWD01000A097 W SET - 100 Free bright alu - --- 1000 130x7,4x5 1.85 GWD010003021 W SET - 100 Free black - --- 1000 130x7,4x5 1.85 Height 2000 mm
28 Elegant metal strut that fits the clean look of the enclosure Minimalist chromed rest matches the top strut Walk-In Walk-In Corner Two fixed walls with entrance from one side Shower channels è An elegant shower enclosure solution. Practical by being closed off on one end. Closed off from one side 4. 8 mm safety glass with patented RAVAK AntiCalc® technology. 3. The W SET contains metal struts, U washers, glass seals and the mounting kit. The glass pane package includes the glass pane and a fixing profile. 2. For a complete product, it is necessary to order a WalkIn Corner glass pane pack separately and a W SET-Corner separately. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Seats è Faucets è Accessories è Detergents è 262 222 472 564 601
ravak.com 29 BRIGHT ALU TRANSPARENT GRAPHITE BLACK MATELux MATRIx Design Standard panelling Atypical panelling Products are delivered within 14 days as standard. For a complete product, it is necessary to order a Walk-In Corner glass pane pack separately and a W SET-Corner separately. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks. 5-YEAR WARRANTY 5 L/R OPTION L/R GLASS PROTECTION ANTICALC EASY MAINTENANCE GLASS THICKNESS 8 mm Walk-In Corner Order No. Type Frame Panelling Product dimensions (mm) „V“ entrance (mm) Size of packaging (cm) Gross weight (kg) GW1CD4300Z1 Walk-In Corner - 110/80 black transparent 1100x800 800 115x16x205 89.5 GWD010003017 W SET - 80 Wall/Corner black - --- 800 110x7,4x5 1.19 GW1CD4C00Z1 Walk-In Corner - 110/80 bright alu transparent 1100x800 800 115x16x205 89.5 GWD01000A093 W SET - 80 Wall/Corner bright alu - --- 800 110x7,4x5 1.19 GW1CG4300Z1 Walk-In Corner - 120/80 black transparent 1200x800 800 125x16x205 93.5 GWD010003017 W SET - 80 Wall/Corner black - --- 800 110x7,4x5 1.19 GW1CG4C00Z1 Walk-In Corner - 120/80 bright alu transparent 1200x800 800 125x16x205 93.5 GWD01000A093 W SET - 80 Wall/Corner bright alu - --- 800 110x7,4x5 1.19 GW1CG7300Z1 Walk-In Corner - 120/90 black transparent 1200x900 900 125x16x205 97.5 GWD010003018 W SET - 90 Wall/Corner black - --- 900 120x7,4x5 1.24 GW1CG7C00Z1 Walk-In Corner - 120/90 bright alu transparent 1200x900 900 125x16x205 97.5 GWD01000A094 W SET - 90 Wall/Corner bright alu - --- 900 120x7,4x5 1.24 Height 2000 mm
30 Elegant metal strut that fits the clean look of the enclosure Minimalist chromed rest matches the top strut Walk-In Walk-In Wall One fixed wall with entrance from one side Shower channels è A modern solution for a corner showering space. Corner solution 5. 8 mm safety glass with patented RAVAK AntiCalc® technology. 4. The W SET contains metal struts, U washers, glass seals and the mounting kit. The glass pane package includes the glass pane and a fixing profile. 3. W SET-Uni Free/Wall has a length of 1,200 mm. Can be cut to shorten it to any size and create the exact entrance width you need. 2. To complete your shower enclosure, it is necessary to order the Walk-In Wall glass pane along with W SET-Uni Free/Wall (recommended), or with W SET-Wall/Corner of the chosen size. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Seats è Faucets è Accessories è Detergents è 262 222 472 564 601
ravak.com 31 BRIGHT ALU TRANSPARENT GRAPHITE BLACK MATELux MATRIx Design Standard panelling Atypical panelling Products are delivered within 14 days as standard. For a complete product, it is necessary to order a Walk-In glass pane pack separately and a W SET-Wall separately. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks. 5-YEAR WARRANTY 5 L/R OPTION L/R GLASS PROTECTION ANTICALC EASY MAINTENANCE GLASS THICKNESS 8 mm Walk-In Wall Order No. Type Frame Panelling Product dimensions (mm) „V“ entrance (mm) Size of packaging (cm) Gross weight (kg) GW9W00300Z1 Walk-In Wall - 60 black transparent 600 65x8x205 30.4 GW9W00C00Z1 Walk-In Wall - 60 bright alu transparent 600 65x8x205 30.3 GW9W10300Z1 Walk-In Wall - 70 black transparent 700 75x8x205 34.9 GW9W10C00Z1 Walk-In Wall - 70 bright alu transparent 700 75x8x205 34.9 GW9W40300Z1 Walk-In Wall - 80 black transparent 800 85x8x205 39 GW9W40C00Z1 Walk-In Wall - 80 bright alu transparent 800 85x8x205 39 GW9W70300Z1 Walk-In Wall - 90 black transparent 900 95x8x205 40.27 GW9W70C00Z1 Walk-In Wall - 90 bright alu transparent 900 95x8x205 40.27 GW9WA0300Z1 Walk-In Wall - 100 black transparent 1000 105x8x205 43.96 GW9WA0C00Z1 Walk-In Wall - 100 bright alu transparent 1000 105x8x205 43.96 GW9WD0300Z1 Walk-In Wall - 110 black transparent 1100 115x8x205 47.54 GW9WD0C00Z1 Walk-In Wall - 110 bright alu transparent 1100 115x8x205 47.54 GW9WG0300Z1 Walk-In Wall - 120 black transparent 1200 125x8x205 51.43 GW9WG0C00Z1 Walk-In Wall - 120 bright alu transparent 1200 125x8x205 51.43 GW9WJ0300Z1 Walk-In Wall - 130 black transparent 1300 135x8x205 60.7 GW9WJ0C00Z1 Walk-In Wall - 130 bright alu transparent 1300 135x8x205 60.7 GW9WM0300Z1 Walk-In Wall - 140 black transparent 1400 145x8x205 64.8 GW9WM0C00Z1 Walk-In Wall - 140 bright alu transparent 1400 145x8x205 64.7 GW9WP0300Z1 Walk-In Wall - 150 black transparent 1500 155x8x205 71.1 GW9WP0C00Z1 Walk-In Wall - 150 bright alu transparent 1500 155x8x205 71.2 GW9WS0300Z1 Walk-In Wall - 160 black transparent 1600 165x8x205 75.2 GW9WS0C00Z1 Walk-In Wall - 160 bright alu transparent 1600 165x8x205 75.2 GWD01000A098 W SET - Uni Free/Wall bright alu - --- max. 1200 6x10x125 1.46 GWD010003023 W SET - Uni Free/Wall black - --- max. 1200 6x10x125 1.45 GWD01000A093 W SET - 80 Wall/Corner bright alu - --- 800 110x7,4x5 1.19 GWD010003017 W SET - 80 Wall/Corner black - --- 800 110x7,4x5 1.19 GWD01000A094 W SET - 90 Wall/Corner bright alu - --- 900 120x7,4x5 1.24 GWD010003018 W SET - 90 Wall/Corner black - --- 900 120x7,4x5 1.24 GWD01000A095 W SET - 100 Wall/Corner bright alu - --- 1000 130x7,4x5 1.34 GWD010003019 W SET - 100 Wall/Corner black - --- 1000 130x7,4x5 1.34 Height 2000 mm
32 Elegant metal strut that fits the clean look of the enclosure Minimalist chromed rest matches the top strut Walk-In Walk-In Double Wall two fixed walls with entrance from one side Shower channels è A modern solution for a corner showering space. Corner solution 5. 8 mm safety glass with patented RAVAK AntiCalc® technology. 4. The W SET contains metal struts, U washers, glass seals and the mounting kit. The glass pane package includes the glass pane and a fixing profile. 3. Reducing the W SET-Uni Free/Wall dimensions allows you to adjust the width of the showering space, while changing the dimensions of the W SET-Uni T connector changes the width of the entrance to the shower enclosure. 2. To complete your shower enclosure, it is necessary to order two Walk-In Wall glass panels in your size of choice along with W SETUni Free/Wall and W SETUni T connector. The length of the W sets is 1,200 mm. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Seats è Faucets è Accessories è Detergents è 262 222 472 564 601
ravak.com 33 BRIGHT ALU TRANSPARENT GRAPHITE BLACK MATELux MATRIx Design Standard panelling Atypical panelling Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks. 5-YEAR WARRANTY 5 L/R OPTION L/R Walk-In Double Wall Height 2000 mm Products are delivered within 14 days as standard. For a complete product, it is necessary to order a Walk-In glass pane pack separately and a W SET-Wall separately. Order No. Type Frame Panelling Product dimensions (mm) „V“ entrance (mm) Size of packaging (cm) Gross weight (kg) GW9W00300Z1 Walk-In Wall - 60 black transparent 600 65x8x205 30.4 GW9W00C00Z1 Walk-In Wall - 60 bright alu transparent 600 65x8x205 30.3 GW9W10300Z1 Walk-In Wall - 70 black transparent 700 75x8x205 34.9 GW9W10C00Z1 Walk-In Wall - 70 bright alu transparent 700 75x8x205 34.9 GW9W40300Z1 Walk-In Wall - 80 black transparent 800 85x8x205 39 GW9W40C00Z1 Walk-In Wall - 80 bright alu transparent 800 85x8x205 39 GW9W70300Z1 Walk-In Wall - 90 black transparent 900 95x8x205 40.27 GW9W70C00Z1 Walk-In Wall - 90 bright alu transparent 900 95x8x205 40.27 GW9WA0300Z1 Walk-In Wall - 100 black transparent 1000 105x8x205 43.96 GW9WA0C00Z1 Walk-In Wall - 100 bright alu transparent 1000 105x8x205 43.96 GW9WD0300Z1 Walk-In Wall - 110 black transparent 1100 115x8x205 47.54 GW9WD0C00Z1 Walk-In Wall - 110 bright alu transparent 1100 115x8x205 47.54 GW9WG0300Z1 Walk-In Wall - 120 black transparent 1200 125x8x205 51.43 GW9WG0C00Z1 Walk-In Wall - 120 bright alu transparent 1200 125x8x205 51.43 GW9WJ0300Z1 Walk-In Wall - 130 black transparent 1300 135x8x205 60.7 GW9WJ0C00Z1 Walk-In Wall - 130 bright alu transparent 1300 135x8x205 60.7 GW9WM0300Z1 Walk-In Wall - 140 black transparent 1400 145x8x205 64.8 GW9WM0C00Z1 Walk-In Wall - 140 bright alu transparent 1400 145x8x205 64.7 GW9WP0300Z1 Walk-In Wall - 150 black transparent 1500 155x8x205 71.1 GW9WP0C00Z1 Walk-In Wall - 150 bright alu transparent 1500 155x8x205 71.2 GW9WS0300Z1 Walk-In Wall - 160 black transparent 1600 165x8x205 75.2 GW9WS0C00Z1 Walk-In Wall - 160 bright alu transparent 1600 165x8x205 75.2 GWD01000A098 W SET - Uni Free/Wall bright alu - --- max. 1200 6x10x125 1.46 GWD010003023 W SET - Uni Free/Wall black - --- max. 1200 6x10x125 1.45 GWD01000A099 W SET - Uni T connection bright alu - --- 6x10x125 1.02 GWD010003024 W SET - Uni T connection black - --- 6x10x125 1.02 GLASS PROTECTION ANTICALC EASY MAINTENANCE GLASS THICKNESS 8 mm
34 Walk-In Walk-In Free Structural preparation Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) Walk In Free - 120 In accordance with technical drawings Walk In Free - 130 - In accordance with technical drawings Walk In Free - 140 - In accordance with technical drawings Walk In Free - 150 - In accordance with technical drawings Walk In Free - 160 - In accordance with technical drawings * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass.
ravak.com 35 Walk-In Walk-In Corner Structural preparation * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass. Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) Walk In Corner - 110/80 1092 x 792 Walk In Corner - 120/80 1192 x 792 Walk In Corner - 120/90 1192 x 892
36 Walk-In Walk-In Wall Structural preparation * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass. Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) Walk In Wall - 60 - In accordance with technical drawings Walk In Wall - 70 - In accordance with technical drawings Walk In Wall - 80 - In accordance with technical drawings Walk In Wall - 90 - In accordance with technical drawings Walk In Wall - 100 - In accordance with technical drawings Walk In Wall - 110 - In accordance with technical drawings Walk In Wall - 120 - In accordance with technical drawings Walk In Wall - 130 - In accordance with technical drawings Walk In Wall - 140 - In accordance with technical drawings Walk In Wall - 150 - In accordance with technical drawings Walk In Wall - 160 - In accordance with technical drawings
ravak.com 37 Walk-In Walk-In Double Wall Structural preparation Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) Walk In Wall - 60 - In accordance with technical drawings Walk In Wall - 70 - In accordance with technical drawings Walk In Wall - 80 - In accordance with technical drawings Walk In Wall - 90 - In accordance with technical drawings Walk In Wall - 100 - In accordance with technical drawings Walk In Wall - 110 - In accordance with technical drawings Walk In Wall - 120 - In accordance with technical drawings Walk In Wall - 130 - In accordance with technical drawings Walk In Wall - 140 - In accordance with technical drawings Walk In Wall - 150 - In accordance with technical drawings Walk In Wall - 160 - In accordance with technical drawings * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass.
38 Brilliant
ravak.com 39 Honed perfection Uncompromising quality of materials and handmade details make Briliant a masterpiece Smart solution Lifting mechanism makes sure the door closes shut automatically Easier maintenance Hinges are recessed into the glass on the inside to facilitate cleaning Water-tightness Side sealing strips are led through a metal fitting to make sure water has no weak points to escape through. Bottom driprail and threshold strip (18 mm) prevent water from spraying out of the enclosure. Long life guaranteed Robust metal elements with high-quality chrome-plating guarantee 30-year life Easy maintenance Thanks to a protective RAVAK AntiCalc® layer, the glass stays clean for longer (no scale sediments) LIFTING MECHANISM Lifts the door and secures it in its basic position GLASS PROTECTION The glass is protected by RAVAK AntiCalc® surface treatment technology 5 5-YEAR WARRANTY ON ALL SHOWER ENCLOSURES AND DOORS Corner shower enclosures > 40 Shower door with a fixed wall > 42 Shower doors > 44 BSRV4 BSDPS BSD2 GLASS THICKNESS 8/6 mm B SET LIFESPAN TESTED TO 30 YEARS High-quality chrome-plated fittings with minimum life of 30 years Shower enclosures Brilliant
40 Recessed hinges on the inside for easy enclosure maintenance Long life thanks to robust metal hinges, fixtures and handle Perfect water-tightness thanks to a threshold strip and vertical seals Brilliant BSRV4 Corner entry four-piece shower enclosure Very comfortable access to the enclosure thanks to above-standard entrance width of up to 90 cm. Wide range of shapes and sizes Shower trays 230 è 5. The threshold strip is 18 mm tall, short holder is 268 mm long, long holder is 570 mm long. 4. To get a complete product, it is necessary to order BSRV4 glass panes separately and a B SET (contains hinges, fixtures, handles, holder) separately. 3. The fixed walls are made of 8mm and the doors of 6mm safety glass with patented RAVAK AntiCalc® technology. 2. Recommended shower trays: Perseus Pro, Perseus Pro Flat, Perseus Pro Chrome, Perseus Pro 10°. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. Important Shower channels 262 è Seats 222 è Faucets 472 è Accessories 564 è
ravak.com 41 Order No. Type Frame Panelling Dimensions (mm) Size of packaging (cm) Gross weight (kg) „A“ „B“ „S“ „V“ 1UV44A00Z1 BSRV4 - 80 - transparent 783-795 554 228 763 69,5x11x201,5 58.4 D01000A073 B SET chrome - 9x12x62 6.02 1UV77A00Z1 BSRV4 - 90 - transparent 883-895 554 328 763 69,5x11x201,5 65.96 D01000A073 B SET chrome - 9x12x62 6.02 1UVAAA00Z1 BSRV4 - 100 - transparent 983-995 654 328 905 69,5x11x201,5 71.79 D01000A074 B SET chrome - 9x12x62 7.14 TRANSPARENT GRAPHITE GRAPE MATELux MATRIx Design Standard panelling Atypical panelling B SET BSRV4 100 = B SET BSRV4 80/90 = ○ ■ ○ ○ ■ 5-YEAR WARRANTY 5 LIFESPAN TEST 30 YEARS B SET GLASS PROTECTION ANTICALC GLASS THICKNESS 8/6 mm LIFTING MECHANISM Brilliant BSRV4 Height 1950 mm Products are delivered within 14 days as standard. For a complete product, it is necessary to order a glass pane pack separately and a B SET separately. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks.
42 Recessed hinges on the inside for easy enclosure maintenance Long life thanks to robust metal hinges, fixtures and handle Perfect water-tightness thanks to a threshold strip and vertical seals Brilliant BSDPS Shower door with a fixed wall Fixed walls and doors available in multiple sizes – choose square or rectangular shower enclosure according to your wishes and needs. Wide range of shapes and sizes Shower trays è 5. The threshold strip is 18 mm tall, short holder is 268 mm long, long holder is 570 mm long. 4. To get a complete product, it is necessary to order BSDPS glass panes separately and a B SET (contains hinges, fixtures, handles, holder) separately. 3. The fixed walls are made of 8mm and the doors of 6mm safety glass with patented RAVAK AntiCalc® technology. 2. Recommended shower trays: Perseus Pro, Perseus Pro Flat, Perseus Pro Chrome, Perseus Pro 10°. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Shower channels è Seats è Faucets è Accessories è 230 262 222 472 564
ravak.com 43 Order No. Type Frame Panelling Dimensions (mm) Size of packaging (cm) Gross weight (kg) „A“ „B“ „C“ „S“ „V“ 0UL44A00Z1 BSDPS - 80 L - transparent 783-795 554 783-795 228 527 77x8x193 64.2 D01000A076 B SET chrome - 9x12x62 5.08 0UP44A00Z1 BSDPS - 80 P - transparent 783-795 554 783-795 228 527 75x8x193 64.2 D01000A075 B SET chrome - 9x12x62 5.08 0UL77A00Z1 BSDPS - 90 L - transparent 883-895 554 883-895 328 527 87x8x193 72.76 D01000A076 B SET chrome - 9x12x62 5.08 0UP77A00Z1 BSDPS - 90 P - transparent 883-895 554 883-895 328 527 87x8x193 72.76 D01000A075 B SET chrome - 9x12x62 5.08 0ULA0A00Z1 BSDPS - 100 L - transparent 983-995 654 983-995 328 627 97x8x193 78.85 D01000A078 B SET chrome - 9x12x62 5.62 0UPA0A00Z1 BSDPS - 100 P - transparent 983-995 654 983-995 328 627 97x8x193 78.85 D01000A077 B SET chrome - 9x12x62 5.62 0ULA4A00Z1 BSDPS - 100/80 L - transparent 983-995 654 783-795 328 627 77x8x193 71.26 D01000A078 B SET chrome - 9x12x62 5.62 0UPA4A00Z1 BSDPS - 100/80 P - transparent 983-995 654 783-795 328 627 77x8x193 71.26 D01000A077 B SET chrome - 9x12x62 5.62 0ULD4A00Z1 BSDPS - 110/80 L - transparent 1083-1095 654 783-795 428 627 77x8x193 75.22 D01000A080 B SET chrome - 9x12x62 5.62 0UPD4A00Z1 BSDPS - 110/80 P - transparent 1083-1095 654 783-795 428 627 76x8x193 75.22 D01000A079 B SET chrome - 9x12x62 5.62 0ULG4A00Z1 BSDPS - 120/80 L - transparent 1183-1195 654 783-795 528 627 77x8x193 79.17 D01000A082 B SET chrome - 9x12x62 5.84 0UPG4A00Z1 BSDPS - 120/80 P - transparent 1183-1195 654 783-795 528 627 77x8x193 79.17 D01000A081 B SET chrome - 9x12x62 5.84 0ULG7A00Z1 BSDPS - 120/90 L - transparent 1183-1195 654 883-895 528 627 87x8x193 83.47 D01000A082 B SET chrome - 9x12x62 5.84 0UPG7A00Z1 BSDPS - 120/90 P - transparent 1183-1195 654 883-895 528 627 87x8x193 83.47 D01000A081 B SET chrome - 9x12x62 5.84 TRANSPARENT GRAPHITE GRAPE MATELux MATRIx Design Standard panelling Atypical panelling B SET BSDPS-L/R 100/110 = B SET BSDPS-L/R 120 = B SET BSDPS-L/R 80/90 = ○ ■ ■ ▼ ○ ○ ▼ ○ ○ ■ ■ ■ ■ ■ 5-YEAR WARRANTY 5 LIFESPAN TEST 30 YEARS B SET GLASS PROTECTION ANTICALC GLASS THICKNESS 8/6 mm LIFTING MECHANISM L/R OPTION L/R Brilliant BSDPS Height 1950 mm Products are delivered within 14 days as standard. For a complete product, it is necessary to order a glass pane pack separately and a B SET separately. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks. L ▼ ▼ ▼
44 Recessed hinges on the inside for easy enclosure maintenance Long life thanks to robust metal hinges, fixtures and handle Perfect water-tightness thanks to a threshold strip and vertical seals Brilliant BSD2 Two-piece shower door The ideal solution for creating a showering space in an 80 to 100 cm wide bathroom niche. A genius solution for niches Shower trays è 5. The threshold strip is 18 mm tall, short holder is 268 mm long, long holder is 570 mm long. 4. To get a complete product, it is necessary to order BSD2 glass panes separately and a B SET (contains hinges, fixtures, handles, holder) separately. 3. The fixed walls are made of 8mm and the doors of 6mm safety glass with patented RAVAK AntiCalc® technology. 2. Recommended shower trays: Perseus Pro, Perseus Pro Flat, Perseus Pro Chrome, Perseus Pro 10°. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. Important Shower channels è Seats è Faucets è Accessories è 230 262 222 472 564
ravak.com 45 Order No. Type Frame Panelling Dimensions (mm) Size of packaging (cm) Gross weight (kg) „A“ „B“ „S“ „V“ 0UL4AA00Z1 BSD2 - 80 L - transparent 790-805 554 218 529 54x4x193 31.07 D01000A084 B SET chrome - 9x12x28 3.2 0UP4AA00Z1 BSD2 - 80 P - transparent 790-805 554 218 529 55x4x193 31.07 D01000A083 B SET chrome - 9x12x28 3.2 0UL7AA00Z1 BSD2 - 90 L - transparent 890-905 554 318 529 55x4x193 35.33 D01000A084 B SET chrome - 9x12x28 3.2 0UP7AA00Z1 BSD2 - 90 P - transparent 890-905 554 318 529 55x4x193 35.33 D01000A083 B SET chrome - 9x12x28 3.2 0ULAAA00Z1 BSD2 - 100 L - transparent 990-1005 654 318 629 56x4x193 38.45 D01000A086 B SET chrome - 9x12x28 3.92 0UPAAA00Z1 BSD2 - 100 P - transparent 990-1005 654 318 629 56x4x193 38.45 D01000A085 B SET chrome - 9x12x62 3.92 TRANSPARENT GRAPHITE GRAPE MATELux MATRIx Design Standard panelling Atypical panelling B SET BSD2-L/R 100 = B SET BSD2-L/R 80/90 = ○ ■ ○ ○ ○ ○ ■ ■ 5-YEAR WARRANTY 5 LIFESPAN TEST 30 YEARS B SET GLASS PROTECTION ANTICALC GLASS THICKNESS 8/6 mm LIFTING MECHANISM L/R OPTION L/R Brilliant BSD2 Height 1950 mm Products are delivered within 14 days as standard. For a complete product, it is necessary to order a glass pane pack separately and a B SET separately. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks.
46 Brilliant BSRV4 Structural preparation Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) "BSRV4 - 80 800 x 800 774 x 774 "BSRV4 - 90 900 x 900 874 x 874 "BSRV4 - 100 1000 x 1000 974 x 974 * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass.
ravak.com 47 Brilliant BSDPS Structural preparation * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass. Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) BSDPS - 80 L/R 800 x 800 774 x 774 BSDPS - 90 L/R 900 x 900 874 x 874 BSDPS - 100 L/R 1000 x 1000 974 x 974 BSDPS - 100/80 L/R 1000 x 800 974 x 774 BSDPS - 110/80 L/R 1100 x 800 1074 x 774 BSDPS - 120/80 L/R 1200 x 800 1174 x 774 BSDPS - 120/90 L/R 1200 x 900 1174 x 874 Type „A“ „B“ „L1“ „L2“ „C“ „R“ „V“ „A1“ „B1“ BSDPS - 80 L/R 789 (783-795) 789 (783-795) 750 750 228 554 - 774 (±6) 774 (±6) BSDPS - 90 L/R 889 (883-895) 889 (883-895) 850 850 328 554 - 874 (±6) 874 (±6) BSDPS - 100 L/R 989 (983-995) 989 (983-995) 950 950 328 654 173 974 (±6) 974 (±6) BSDPS - 100/80 L/R 989 (983-995) 789 (783-795) 950 750 328 654 173 974 (±6) 774 (±6) BSDPS - 110/80 L/R 1089 (1083-1095) 789 (783-795) 1050 750 428 654 173 1074 (±6) 774 (±6) BSDPS - 120/80 L/R 1189 (1183-1195) 789 (783-795) 1150 750 528 654 378 1174 (±6) 774 (±6) BSDPS - 120/90 L/R 1189 (1183-1195) 889 (883-895) 1150 850 528 654 378 1174 (±6) 874 (±6)
48 Notes
ravak.com 49 Brilliant BSD2 Structural preparation Brilliant
50 SmartLine
ravak.com 51 Quadrant shower enclosures > 52 Corner shower enclosures > 54 Shower doors > 56 Fixed wall > 58 SMSKK4 SMSRV4 SMSD2 SMPS LIFTING MECHANISM Lifts the door and secures it in its basic position GLASS PROTECTION The glass is protected by RAVAK AntiCalc® surface treatment technology 5 5-YEAR WARRANTY ON ALL SHOWER ENCLOSURES AND DOORS GLASS THICKNESS Lustrous and minimalist design Glass surfaces with glossy metal fittings for an airy and lightweight look Short side holders for ensuring perfect and long-term stability of the enclosure Technical perfection in its class Robust metal chrome-plated hinges with lifting mechanism for automatic soft closing Accommodates structural inaccuracies in the bathroom The product can be adjusted by up to 15mm on each side Water-tightness Vertical side profiles combined with sealing strips on the doors provide high water-tightness. Bottom drip-rail and threshold strip (18 mm) prevents water from spraying out of the enclosure Easy maintenance Thanks to a protective RAVAK AntiCalc® layer, the glass stays clean for longer (no scale sediments) 6 mm Shower enclosures SmartLine
52 Fixing profile can compensate even for major structural inaccuracies in the bathroom Perfect water-tightness thanks to a threshold strip and vertical seals Robust and ergonomic metal handle SmartLine SMSKK4 Quadrant four-piece shower enclosure Very comfortable access to the enclosure thanks to entrance width of up to 76 cm. A comfortably wide entrance Shower trays è 4. Radius R500. 3. Delivery includes 2 short 270 mm holders. 2. The threshold strip is 18 mm tall. 1. Recommended shower trays: Elipso, Elipso Pro, Elipso Pro Flat, Elipso Pro Chrome, Ronda, Sabina. Important Shower channels è Seats è Faucets è Accessories è 230 262 222 472 564
ravak.com 53 Order No. Type Frame Panelling Dimensions (mm) Size of packaging (cm) Gross weight (kg) „A“ „B“ „S“ „V“ 3S244A00Y1 SMSKK4 - 80 bright alu/ chrome transparent 785-800 441 228 761 47x20x201 51.3 3S277A00Y1 SMSKK4 - 90 bright alu/ chrome transparent 885-900 441 328 761 47x20x201 56.8 BRIGHT ALU TRANSPARENT Design Standard panelling 5-YEAR WARRANTY 5 LIFTING MECHANISM GLASS PROTECTION ANTICALC GLASS THICKNESS 6 mm SmartLine SMSKK4 Height 1900 mm Products are delivered within 14 days as standard. Delivery time of atypical products is 6-8 weeks.
54 Fixing profile can compensate even for major structural inaccuracies in the bathroom Perfect water-tightness thanks to a threshold strip and vertical seals Robust and ergonomic metal handle SmartLine SMSRV4 Corner entry four-piece shower enclosure Very comfortable access to the enclosure thanks to entrance width of up to 76 cm. A comfortably wide entrance Shower trays è 4. Delivery includes 2 short 270 mm holders. 3. The threshold strip is 18 mm tall. 2. Recommended shower trays: Perseus Pro, Perseus Pro Flat, Perseus Pro Chrome, Perseus Pro 10°, Angela. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Shower channels è Seats è Faucets è Accessories è 230 262 222 472 564
ravak.com 55 Order No. Type Frame Panelling Dimensions (mm) Size of packaging (cm) Gross weight (kg) „A“ „B“ „S“ „V“ 1SV44A00Z1 SMSRV4 - 80 bright alu/ chrome transparent 785-800 554 228 763 71x8x193 56.8 1SV77A00Z1 SMSRV4 - 90 bright alu/ chrome transparent 885-900 554 328 763 71x8x193 62.3 BRIGHT ALU TRANSPARENT GRAPHITE GRAPE MATELux MATRIx Design Standard panelling Atypical panelling 5-YEAR WARRANTY 5 LIFTING MECHANISM GLASS PROTECTION ANTICALC GLASS THICKNESS 6 mm SmartLine SMSRV4 Height 1900 mm Products are delivered within 14 days as standard. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks.
56 Fixing profile can compensate even for major structural inaccuracies in the bathroom Perfect water-tightness thanks to a threshold strip and vertical seals Robust and ergonomic metal handle SmartLine SMSD2 Two-piece shower door The ideal solution for creating a showering space in a 90 to 120 cm wide bathroom niche, or creating a shower enclosure when combined with PPS fixed wall. A comfortably wide entrance Shower trays è 5. Includes 1 short 270 mm holder; only 120 cm door comes with 1 long 571 mm holder. 4. The threshold strip is 18 mm tall. 3. When installing the product into a niche, either the A or the B variant of the product can be used depending on the size of the opening. To combine the door with a fixed wall, only the B variant can be used. 2. Recommended shower trays: Perseus Pro, Perseus Pro Flat, Perseus Pro Chrome A 10°, Gigant, Gigant Pro, Gigant Pro Flat, Gigant Pro Chrome and 10°, Angela. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Shower channels è Seats è Faucets è Accessories è 230 262 222 472 564
ravak.com 57 Order No. Type Frame Panelling Dimensions (mm) Size of packaging (cm) Gross weight (kg) „A“ „B“ „S“ „V“ 0SL7AA00Z1 SMSD2 - 90 A-L bright alu/ chrome transparent 889-906 654 218 629 69,5x11x201,5 37.24 0SP7AA00Z1 SMSD2 - 90 A-P bright alu/ chrome transparent 889-906 654 218 629 69,5x11x201,5 37.24 0SL7BA00Z1 SMSD2 - 90 B-L bright alu/ chrome transparent 899-916 654 228 629 69,5x11x201,5 37.51 0SP7BA00Z1 SMSD2 - 90 B-P bright alu/ chrome transparent 899-916 654 228 629 69,5x11x201,5 37.51 0SLAAA00Z1 SMSD2 - 100 A-L bright alu/ chrome transparent 989-1006 654 318 629 69,5x11x201,5 40.02 0SPAAA00Z1 SMSD2 - 100 A-P bright alu/ chrome transparent 989-1006 654 318 629 69,5x11x201,5 40.02 0SLABA00Z1 SMSD2 - 100 B-L bright alu/ chrome transparent 999-1016 654 328 629 69,5x11x201,5 40.29 0SPABA00Z1 SMSD2 - 100 B-P bright alu/ chrome transparent 999-1016 654 328 629 69,5x11x201,5 40.29 0SLDAA00Z1 SMSD2 - 110 A-L bright alu/ chrome transparent 1089-1106 654 418 629 69,5x11x201,5 42.78 0SPDAA00Z1 SMSD2 - 110 A-P bright alu/ chrome transparent 1089-1106 654 418 629 69,5x11x201,5 42.78 0SLDBA00Z1 SMSD2 - 110 B-L bright alu/ chrome transparent 1099-1116 654 428 629 69,5x11x201,5 43.06 0SPDBA00Z1 SMSD2 - 110 B-P bright alu/ chrome transparent 1099-1116 654 428 629 69,5x11x201,5 43.06 0SLGAA00Z1 SMSD2 - 120 A-L bright alu/ chrome transparent 1189-1206 654 518 629 69,5x11x201,5 45.67 0SPGAA00Z1 SMSD2 - 120 A-P bright alu/ chrome transparent 1189-1206 654 518 629 69,5x11x201,5 45.67 0SLGBA00Z1 SMSD2 - 120 B-L bright alu/ chrome transparent 1199-1216 654 528 629 69,5x11x201,5 45.94 0SPGBA00Z1 SMSD2 - 120 B-P bright alu/ chrome transparent 1199-1216 654 528 629 69,5x11x201,5 45.94 BRIGHT ALU TRANSPARENT GRAPHITE GRAPE MATELux MATRIx Design Standard panelling Atypical panelling 5-YEAR WARRANTY 5 LIFTING MECHANISM GLASS PROTECTION ANTICALC GLASS THICKNESS 6 mm L/R OPTION L/R SmartLine SMSD2 Height 1900 mm Products are delivered within 14 days as standard. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks.
58 Fixing profile can compensate even for major structural inaccuracies in the bathroom Robust holder for perfect stability Robust and ergonomic metal handle SmartLine SMPS Fixed wall Shower trays è Space next to the fixed wall of the shower enclosure can serve as the perfect spot for your washing machine, washbasin, toilet... A practical solution 5. Left-sided door combines with a left-sided fixed wall. Rightsided door combines with a right-sided fixed wall. 4. The fixed wall is designed to combine with SMSD2 shower door, model B. 3. The product can also be used separately as a partition, but is primarily designed for combining with SMSD2 shower door. 2. Recommended shower trays: Perseus Pro, Perseus Pro Flat, Perseus Pro Chrome A 10°, Gigant, Gigant Pro, Gigant Pro Flat, Gigant Pro Chrome and 10°, Angela. 1. Recommended drains and shower channels: Chrome, 10° and Runway stainless shower channels. Zebra plastic shower channels with stainless grate. SN501 plastic drain with stainless grate. Important Shower channels è Seats è Faucets è Accessories è 230 262 222 472 564
ravak.com 59 BRIGHT ALU TRANSPARENT GRAPHITE GRAPE MATELux MATRIx Design Standard panelling Atypical panelling Products are delivered within 14 days as standard. Assemble a product exactly as you need – online, with a visual preview in a bathroom at https://atypical.ravak.com Delivery time of atypical products is 6-8 weeks. 5-YEAR WARRANTY 5 LIFTING MECHANISM GLASS PROTECTION ANTICALC GLASS THICKNESS 6 mm L/R OPTION L/R SmartLine SMPS Order No. Type Frame Panelling Product dimensions (mm) Size of packaging (cm) Gross weight (kg) 9SL40A00Z1 SMPS - 80 L bright alu transparent 785-800 77x4x193 27.3 9SP40A00Z1 SMPS - 80 P bright alu transparent 785-800 77x4x193 27.3 9SL70A00Z1 SMPS - 90 L bright alu transparent 885-900 87x4x193 30 9SP70A00Z1 SMPS - 90 P bright alu transparent 885-900 87x4x193 30 9SLA0A00Z1 SMPS - 100 L bright alu transparent 985-1000 97x4x193 32.7 9SPA0A00Z1 SMPS - 100 P bright alu transparent 985-1000 97x4x193 32.7 Height 1900 mm
60 SmartLine SMSKK4 Structural preparation Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) SMSKK4 - 80 800 x 800, R 500 In accordance with technical drawings SMSKK4 - 90 900 x 900, R 500 In accordance with technical drawings * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass.
ravak.com 61 SmartLine SMSRV4 Structural preparation Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) SMSRV4 - 80 800 x 800 775 x 775 SMSRV4 - 90 900 x 900 875 x 875 * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass.
62 SmartLine SMSD2 Structural preparation
ravak.com 63 SMSD2 + SMPS Structural preparation Type Mounting onto a tray * Recommended shower tray size (mm) Floor mounting ** Recommended size of inclined area (mm) SMSD2 - 90 B-L/R + SMPS - 90 L/R 900 x 900 840 x 840 SMSD2 - 100 B-L/R + SMPS - 80 L/R 1000 x 800 940 x 740 SMSD2 - 100 B-L/R + SMPS - 100 L/R 1000 x 1000 940 x 940 SMSD2 - 110 B-L/R + SMPS - 80 L/R 1100 x 800 1040 x 740 SMSD2 - 120 B-L/R + SMPS - 80 L/R 1200 x 800 1140 x 740 SMSD2 - 120 B-L/R + SMPS - 90 L/R 1200 x 900 1140 x 840 * The values listed in the table assume the tray is mounted in accordance with the RAVAK assembly manual ** The values in the table apply to the inside edge of the glass. SmartLine
64 Matrix
ravak.com 65 Corner shower enclosures > 66 Shower doors > 70 GLASS THICKNESS Refined to the last detail The minimalist geometric shapes of the handle, corner joint and threshold strip stand out by their precise manufacturing Sliding mechanism Silent opening, thanks to precise manufacturing and topquality materials Stable top profile Guarantees the structure is sufficiently rigid to last an age Simple maintenance Wheelchair-accessible structure that leaves no nooks for dirt to hide in and facilitates cleaning Quality and luxury without compromise The design is minimalist, almost futuristic in every detail. Easy maintenance Thanks to a protective RAVAK AntiCalc® layer, the glass stays clean for longer (no scale sediments) MSRV4 MSDPS MSD2 GLASS PROTECTION The glass is protected by RAVAK AntiCalc® surface treatment technology EASY MAINTENANCE No profiles or inaccessible places 5 5-YEAR WARRANTY ON ALL SHOWER ENCLOSURES AND DOORS 8/6 mm Shower enclosures Matrix
